Water to Air Intercooler, 17"x12.25"x9", Through I/O (Type 22)

INT000222 by Shaman Equipment

Retail Price: $1,499.99
You Save $950.00 (63%)

PRICE: $549.99

In stock - Ships within One Business Day

This is an enormous water to air intercooler.

The proportions are somewhat ridiculous, please make sure it will fit before ordering. If you have the room, there's nothing better.

The height, its smallest dimension, is nine inches. This intercooler is more than five times larger than our smallest core. Recommended for up to two thousand horsepower.

100% Lightweight aluminum, No Epoxy Used In Core

Fin pitch is 21 fins/inch - 12.5 air side and 8.5 water side.

Recommended for up to 2500 CFM / 2000 HP
Pressure Drop: Less than 0.5 PSI. This is not a typo! Liquid/Air Intercoolers have incredibly low pressure drop.
Inlet: 4" Outlet: 4"
Maximum water/air pressure: 70 PSI
Core Size: 9.5"x9"x9" (Endtanks add to length)
Water to Air Intercoolers The inlet and outlet on this intercooler go directly through the intercooler; preventing the air from changing direction can result in better airflow.
Note: The water inlet and outlet on most water/air intercoolers are BPT threads. BPT fittings are difficult to find in the United States, so ours all come with NPT threads.


Some Water to Air Intercoolers that you can buy online do not contain true water to air cores. A true water to air core has water passages that are much smaller than the air passages. This is part of what allows the water to air intercooler to be so small and have such low pressure drop. Some water to air intercoolers that you buy online use an air to air core design where the air passages for ambient air and intake air are the same size, with an enormous loss of efficiency. Buy from us to make sure that you get a genuine water to air intercooler core!

Water To Air

A liquid to air intercooler setup requires several components, including the core, a water pump, a heat exchanger (radiator), and an optional reservoir. We carry all of the parts you need. Learn about the many benefits of liquid/air by clicking HERE.

Review Summary

5.0 (based on 1 reviews)
100% of respondents would recommend this to a friend.
Write a Review
Reviewed by 1 customers Sort By:
By: Precision Speed Technology

From: SW Florida
5.0 Amazing Value 2014-08-04
Comments about Water to Air Intercooler, 17"x12.25"x9", Through I/O (Type 22):
We are using this intercooler in a twin turbo mustang running 25psi worth of boost and making every bit of 1200rwhp. In dyno and track testing we saw no rise in charge air temps, actually we saw the air temps fall through the passes. This is probably due to ice water in the resevoir getting circulated to the cooler though. Pressure drop through the core as measured with Holley EFI system is actually less than advertised throughout the pulls. Great product with better than advertised performance. And the construction of this thing is increadibly beefy. We have not had any quality related issues, and dont expect to. Actually, I have nothing negative to say about this intercooler.
BOTTOM LINE? Yes, I would recommend this to a friend Was this review helpful? Yes / No
